The Semtrex H-Series is engineered for data center and telecommunications environments, delivering efficient management of physical layer interconnections. It is designed to simplify high-density network organization while maintaining optimal performance.
Featuring a shallow-depth enclosure and front-access cassettes for straightforward installation and maintenance, the H-Series supports high data volumes within a compact footprint.
With a broad selection of flexible connectivity options, the H-Series enables high-performance, high-density networks to expand quickly and efficiently to meet growing bandwidth demands.
Adaptable networking solution built to meet the demands of latency-sensitive applications
Scalable modular design enabling efficient high-density network expansion
Choose from multiple front-loading cassette configurations to achieve flexible, high-density connectivity
Built for efficient installation and easy management, with seamless reconfiguration and maintenance
Drive network uniformity with products supported and supplied across global markets
Power your network with innovative FiberFusion cable technology or fully customizable, end-to-end high-performance fiber assemblies
Complete your deployment with Semtrex fiber raceways, along with racks, cabinets, and mounting frames.
The Semtrex H-Series Housing is a 7RU unit designed with integrated top and bottom cable management for both incoming and outgoing fibers. It accommodates up to 24 H-Series cassettes, providing space for up to 576 LC connections, and can be scaled to support network growth or fully populated for large-scale deployments.
Constructed from aluminum-alloy, the 19” rack-mountable H-Series Housing is lightweight, strong, and can be installed by a single person. Its shallow-depth design (260mm / 10.2”) and front-access-only layout make it ideal for network upgrades or refreshes in both data center and telecom environments.
A flat front door protects the installed assemblies while offering a clean surface for custom exterior labeling. Internally, a comprehensive port labeling table ensures easy identification. Small magnetic door catches and a hinged bottom panel provide secure and convenient access to cassettes and assemblies.
Cable entry is possible from either side of the housing, with 0.75RU of cable management at the top for high fiber count cables and 1.25RU at the bottom for patch cord routing. Integrated cable management maintains proper bend radius for both incoming and outgoing fibers, ensuring optimal network performance while keeping cables organized and easy to manage.
H-Series cassettes are available in a wide range of configurations for multiple applications, including patching, splicing, or fan-outs. The H-Series is unique in that all fiber access is at the front of the cassette.
Populated cassettes are loaded with high-performance, premium assemblies and are available in single-mode and multimode fiber types. H-Series cassettes are compatible with H-Series housings and can be securely installed and removed with snap-in rivets.
